SC APC Fiber Optic Drop Cable Waterproof with 4.8mm 7.0mm Diameter

Ask Lasest Price
Model Number :	Waterproof patch cord
Brand Name :	ODM/OEM
Supply Ability :	200000 Piece/Pieces per Week
Price :	$3.50 - $38.00/pieces
Certification :	RoHS, CE
Payment Terms :	T/T, Western Union

Add to Cart

Product Details
Company Profile

SC APC Fiber Optic Drop Cable Waterproof with 4.8mm 7.0mm Diameter

1 Fiber Fiber Optic H connector SC APC OptiTap to SC/APC FTTH drop Cable Assembly

Product Description

Corning OptiTap Tonable Flat Drop Cable 200FT 300FT Fiber Optic Hardened Drop Cable

Stap cable assemblies provide the most cost-effective method of deploying optical fiber in outside plant distribution networks at speeds significantly fast than traditional field installations. The assemblies guarantee an easy, one-step connection system with the combined push-pull insertion and nut-style mechanical latch. Stap cable assembly provides quick installation solutions and has good performance on mating with Stap adapter. Cable can be amored or non-amored. Stap connector utilizes optical fiber cables upon which network access points are pre-installed at customer-specified locations along the length of the cable.

Applications

1. Fiber optic communications in harsh outdoor environments.

2. Outdoor communications equipment connection.

3. Waterproof fiber equipment SC port.

4. Remote wireless base station.

5. FTTX wiring projiect.

Features

1. Compact size,easy to operate,durable.

2. Easy connection to hardended adapters on terminals or closures.

3. Reduce welding,connect directly to achieve interconnection.

4. IP68 water and dust protection.(1M,1 hour)

5. Spiral clamping mechanism ensures long-term reliable connection.

6. Guide mechanism,can be blinded with one hand,simple and
quick,connect and install.

7. Low operating temperature: - 10 ℃ ~ + 70 ℃

8. Accepts 2.*3.0mm,3.0mm ,5.0mm Cable Diameters

9. Factory or field installation,Allows flexibilityto use factory
terminated and tested assemblies or retrofit to pre-terminated or
field installed assemblies.

SC APC Fiber Optic Drop Cable Waterproof with 4.8mm 7.0mm Diameter

Type	SM-UPC			SM-APC			MM-UPC
Type		Typical	MAX	Typical	MAX	Typical	MAX
Insertion loss	≤0.1	≤0.3dB	≤0.15	≤0.3dB	≤0.05	≤0.3dB
Return loss	≥50dB			≥30dB			≥30dB
Durability	500 mating cycles
Working temperature	-40 to + 85℃

Company Profile

We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. With years of experiences in the fiber optic industry, our factory is fully equipped over 5000 square meters and more than 30 non dust production lines .About 250 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 15 production lines for standard jumper and 8 PLC Splitter production lines. The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on. All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, our fiber optic is looking forward to cooperate with you.

FAQ

Q1. Do you provide OEM ODM service ? Yes, we can print your logo or
label on the products or on the box.

Q2. How can you guarentee the quality ? Build on our perfect
quality management system, all of our products were 100% tested
before the shipment.

Q3. What is your delivery time ? Generally, sample: 3~5 working
days. formal order: 7-10 working days.

Q4. What's the method of shipment? We accept all shipment , such as
Delievery,ocean transport, land transport , airport transport.

Q5. What's the Payment? We accept all payments , such as
LC,TT,DP,DA,Paypal,Western Union,Money Gram.

Q6. Do you provide sample service? A: Yes, we provide free or low
price samples for you to test and check quality. Mixed samples are
acceptable.
