Outdoor Fiber Optic Cable 2 Core 4 Core 6 Core Single Mode G652D GYXTW

Ask Lasest Price
Model Number :	GYXTW
Supply Ability :	100 Kilometer/Kilometers per Week
Price :	$0.30 - $1.00/meters
Brand Name :	ODM/OEM
Certification :	RoHS, CE
Payment Terms :	T/T, Western Union

Add to Cart

Product Details
Company Profile

Outdoor Fiber Optic Cable 2 Core 4 Core 6 Core Single Mode G652D GYXTW

Manufacturing outdoor 2 4 6 core Single Mode G652D fiber Optic Cable GYXTW

The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.

Outdoor Fiber Optic Cable 2 Core 4 Core 6 Core Single Mode G652D GYXTW

Feature

* Good mechanical and temperature performance
* High strength loose tube that is hydrolysis resistant
* Special tube filling compound ensure a critical protection of fiber
* Crush resistance and flexibility
* PSP enhancing moisture-proof
* Two parallel steel wires ensure tensile strength
* Small diameter, light weight and friendly installation
* Long delivery length

Technical data

No. of cable			2~8	10~12	14~24
Fiber Model			G.652D
Strength Member	Material	Steel Wire
Strength Member		Diameter(±0.05)mm	0.8	0.8	0.8
Loose Tube	Material	PBT
		Diameter(±0.06)mm	2.1	2.4	2.8
		Thickness(±0.03)mm	0.32	0.35	0.4
		The Max.Core NO./Tube	8	12	24
Water Blocking layer(Material)			Water Blocking Tape
Armoring	Material	Steel Strip
Armoring		Thickness(±0.03)mm	0.25
Outer Sheath	Material	MDPE
Outer Sheath		Thickness(±0.2)mm	2
Cable Diameter(±0.2)mm			7.9	8.1	8.5
Cable Weight(±5)kg/km			60	63	68
Min. bending radius	Without Tension	10.0×Cable -φ
Min. bending radius		Under Maximum Tension	20.0×Cable -φ
Temperature range(℃)	Installation	-20~+60
		Transport&Storage	-40~+70
		Operation	-40~+70

Application

Our Company

We are a hi-tech enterprise having a self-owned brand and specialize in the R&D, manufacture and sales of fiber optical communications equipment. The main products include all kinds of fiber optic cables, PLC splitters, and terminal boxes. Our products are widely used in telecommunications, broadband, broadcast, CATV and network industry.

We also promise all the features and advantages are the high
technology, which are full of professional and excellent sales
team, efficient and sound management, competitive price, wide and
superior channels, as well as high-quality and flexible service.
